Vigor2762 Series

VDSL2/ADSL2+ Router for Home/SOHO

    Full-Featured Modem/Router for Home and Small Office

    Vigor2762 Series is a VDSL2 modem router that supports all VDSL and ADSL standards. It has four Gigabit LAN ports, one of which is switchable as a WAN interface for broadband Internet access. There are two multi-function USB ports, which can be used for connecting network storage, printers, USB thermometers, or 3G/4G USB modems for cellular connectivity. Vigor2762 Series is highly configurable for an abundance of features including web content filtering, bandwidth limit, QoS, and lots more. The series includes models with built-in 11ac Wi-Fi and VoIP gateway.

    • 100 Mbps

      NAT Throughput on VDSL

    • 2 VPN

      IPsec throughput up to 70Mbps

    • 2 SSL VPN

      Throughput up to 40 Mbps

    • 50k Sessions

      Recommended for a network of 30 hosts

    Key Features

    • null

      Integrated VDSL2 Modem

      Vigor2762 Series provides DSL WAN interface and built-in VDSL modem with ADSL2/2+ fallback.

    • null

      VPN (Virtual Private Network)

      Build a secure and private tunnel from the LAN of Vigor2762 Series to the remote offices and teleworkers over the Internet. Learn more

    • null

      SSL VPN

      The VPN works through firewalls providing secure remote access to any network environment. Learn more

    • null

      VoIP (V models only)

      Vigor2762 Series can act as the SIP gateway, and its RJ-11 ports enable analog phones to make and receive VoIP calls. Setup Guide

    • null

      Bandwidth Management

      Prevent one device using all the bandwidth by bandwidth limit policy, session limit policy, and QoS settings.

    • null

      3G/4G Backup

      The USB ports allow you to plug in a 3G/4G USB modem to take over the traffic when the primary internet connection goes down.

    • null

      Firewall & Content Filter

      Filter web pages by URL keyword or web category to block access to insecure or inappropriate contents.

    • null

      Hotspot Web Portal

      Market your business and communicate with the guests while offering hospitality Wi-Fi. Learn more

    • null

      DrayDDNS

      The free DDNS service for you to access the router by a fixed hostname of your choice. Learn more

    • null

      Central AP Management

      Use the Vigor2762 Series router as a wireless controller to maintain and monitor the VigorAPs. Learn more

    Model 2.4GHz Wi-Fi 5GHz Wi-Fi Wi-Fi Antenna VoIP Gateway FXS RJ-11
    Vigor2762
    Vigor2762n 2x 2.4GHz (2dBi)
    Vigor2762ac 2x Dual-Band (4dBi for 5GHz, 2dBi for 2.4GHz)
    Vigor2762Vac 2x Dual-Band (4dBi for 5GHz, 2dBi for 2.4GHz) 2



    Interface
    Fixed WAN Port 1x RJ-11 for VDSL2 or ADSL2/2+
    LAN/WAN Switchable Port 1x 10/100/1000Base-T, RJ-45 (LAN Port 4)
    Fixed LAN Port 3x 10/100/1000Base-T, RJ-45
    USB Port 2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer
    2.4G WLAN 802.11n 2×2 MIMO 300Mbps (n/ac/Vac model)
    5G WLAN 802.11ac Wave 2 2×2 MIMO 867Mbps (ac/Vac model)
    FXS RJ-11 2 (Vac model)
    Performance
    NAT Throughput 400 Mbps
    NAT Throughput w/ Hardware Acceleration 900 Mbps
    IPsec VPN Performance 70 Mbps (AES 256 bits)
    SSL VPN Performance 40 Mbps
    Max. Number of NAT Sessions 50,000
    Max. Concurrent VPN Tunnels 2
    VDSL/ADSL
    VDSL Standards ITU-T G.993.1 (VDSL), G.997.1, G.993.2 (VDSL2)
    VDSL2 Profile 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a
    VDSL Band Plan 997
    G.INP
    G.Vectoring
    ADSL Standards ANSI T1.413, ITU-T G.992.1(G.dmt), G.992.2 (G.lite)
    ADSL2 Standards ITU-T G.992.3, G.992.3 Annex M/J
    ADSL2+ Standards ITU-T G.992.5, G.992.5 Annex M/J
    DSL Forum WT-114, TR-048/67, TR-100
    Internet Connection
    IPv4 PPPoE, DHCP, Static IP, PPTP/L2TP
    IPv6 PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel
    Multi-VLAN/PVC
    WAN Failover
    Connection Detection ARP, Ping
    WAN Data Budget
    Dynamic DNS
    DrayDDNS
    LAN Management
    VLAN 802.1q Tag-based, Port-based
    Max. Number of VLAN 8
    DHCP Server Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
    Wired 802.1x Authentication
    Port Mirroring
    Local DNS Server
    Conditional DNS Forwarding
    Hotspot Web Portal
    Hotspot Authentication Click-Through, Social Login, SMS PIN, RADIUS, External Portal Server
    Networking
    Routing IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP
    Policy-based Routing Protocol, IP Address, Port, Domain
    DNS Security (DNSSEC)
    Multicast IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour
    SMB File Sharing (Requires external storage)
    VPN
    LAN-to-LAN
    Teleworker-to-LAN
    Protocols PPTP, L2TP, IPsec, L2TP over IPsec, SSL, IKEv2, IKEv2-EAP, IPsec XAuth, OpenVPN
    User Authentication Local, RADIUS, mOTP
    IKE Authentication Pre-Shared Key, X.509
    IPsec Authentication SHA-1, SHA-256, MD5
    Encryption MPPE, DES, 3DES, AES128, AES192, AES256
    Single-Armed VPN
    NAT-Traversal (NAT-T)
    Firewall & Content Filtering
    NAT Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP
    ALG (Application Layer Gateway) SIP, RTSP, FTP, H.323
    VPN Pass-Through PPTP, L2TP, IPsec
    IP-based Firewall Policy
    Content Filtering Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required)
    DoS Attack Defense
    Spoofing Defense
    Bandwidth Management
    IP-based Bandwidth Limit
    IP-based Session Limit
    QoS (Quality of Service) TOS, DSCP, 802.1p, IP Address, Port, Application
    VoIP Prioritization
    Wireless LAN (wireless model)
    Number of SSID 4 per radio band
    Security WEP, WPA, WPA2, WPS
    Authentication Pre-Shared Key, 802.1x
    AirTime Fairness
    Band Steering (dual-band model)
    WMM
    WDS Bridge, Repeater
    Access Control Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling
    VoIP Gateway (V model)
    Protocol SIP, RTP/RTCP, ZRTP
    SIP Registrars 12
    Dial Plan Phone Book, Digit Map, Call Barring, Regional
    Call Features Call Waiting, Call Transfer, Scheduled DND, Hotline
    Voice Codec G.711 A/u law, G.726, G.729 A/B
    Caller ID FSK_ETSI, FSK_BELLCORE, DTMF
    Management
    Local Service HTTP, HTTPS, Telnet, SSH, FTP, TR-069
    Config File Export & Import
    Config File Compatibility Vigor2760 Series
    Firmware Upgrade TFTP, HTTP, TR-069
    2-Level Administration Privilege
    Access Control Access List, Brute Force Protection
    Notification Alert SMS, E-mail
    SNMP v1, v2c, v3
    Syslog
    Managed by VigorACS
    Central AP Management 2 VigorAP
    Physical
    Power Supply DC 12V @ 2A
    Max. Power Consumption 20.4 watts (Vac model)
    Dimension 207mm x 131mm x 42mm
    Weight 450g (Vac model)
    Operating Temperature 0 to 45°C
    Storage Temperature -25 to 70°C
    Operating Humidity (non-condensing) 10 to 90%

    All specifications are subject to change without notice.
