Vigor2832 Series

ADSL2+ & GbE WAN Load Balancing VPN Router

OVERVIEW

    ADSL Modem, Firewall, Router, ALL-in-ONE

    Vigor2832 series is an ADSL2/2+ modem router with an alternative Gigabit Ethernet WAN port for load-balancing or failover. It has 4 Gigabit Ethernet LAN ports and 2 USB ports which can be used for 3G/4G WAN, temperature sensor, or NAS application. Models with built-in 802.11n Wi-Fi are available.

    • Up to 4 WAN

      Load balancing, NAT throughput up to 300 Mbps

    • 32 VPN

      IPsec VPN throughput up to 60 Mbps

    • 10 SSL VPN

      Throughput up to 30 Mbps

    • 50k Sessions

      Recommended for 30 clients

    Key Features

    • null

      Integrated ADSL2/2+ Modem

      Vigor2832 Series provides DSL WAN interface and built-in ADSL2/2+ modem.

    • null

      Load Balancing

      Maximize throughput and reliability by using multiple Internet connections. Learn more

    • null

      VPN (Virtual Private Network)

      Build a secure and private tunnel from the LAN of Vigor2832 Series to the remote offices and teleworkers over the Internet. Learn more

    • null

      SSL VPN

      The VPN works through firewalls providing secure remote access to any network environment. Learn more

    • null

      Firewall & Content Filter

      Filter web pages by URL keyword or web category to block access to insecure or inappropriate contents.

    • null

      Bandwidth Management

      Prevent one device using all the bandwidth by bandwidth limit policy, session limit policy, and QoS settings.

    • null

      Hotspot Web Portal

      Market your business and communicate with the guests while offering hospitality Wi-Fi. Learn more

    • null

      DrayDDNS

      The free DDNS service for you to access the router by a fixed hostname of your choice. Learn more

    MODELS

    Model 2.4G WLAN Antenna
    Vigor2832 – –
    Vigor2832n 2x 2dBi

    SPECS

    Interface
    WAN Port 1x RJ-11 for ADSL2/2+ (WAN1)
    1x Gigabit Ethernet, RJ-45 (WAN2)
    LAN Port 4x Gigabit Ethernet, RJ-45
    USB Port 2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer
    Wi-Fi Antenna 2x External Dipole
    Gain: 2 dBi for 2.4GHz
    (wireless model)
    2.4G WLAN 802.11n 2×2 MIMO
    Up to 300Mbps Link Rate
    (wireless model)
    Performance
    NAT Throughput 300 Mbps
    NAT Throughput w/ Hardware Acceleration 900 Mbps
    IPsec VPN Performance 60 Mbps (AES 256 bits)
    SSL VPN Performance 30 Mbps
    Max. Number of NAT Sessions 50,000
    Max. Concurrent VPN Tunnels 32
    Max. Concurrent OpenVPN + SSL VPN 10
    DSL
    ADSL Standards ANSI T1.413, ITU-T G.992.1(G.dmt), G.992.2 (G.lite)
    ADSL2 Standards ITU-T G.992.3, G.992.3 Annex M/J
    ADSL2+ Standards ITU-T G.992.5, G.992.5 Annex M/J
    Internet Connection
    IPv4 PPPoE, DHCP, Static IP, PPTP/L2TP
    IPv6 PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel
    Multi-VLAN/PVC 8
    3G/4G/LTE WAN with USB modem
    Load Balancing IP-based, Session-based
    WAN Active on Demand Link Failure, Traffic Threshold
    Connection Detection ARP, Ping
    WAN Data Budget
    Dynamic DNS
    DrayDDNS
    LAN Management
    VLAN 802.1q Tag-based, Port-based
    Max. Number of VLAN 8
    Number of LAN Subnet 4
    DHCP Server Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
    Wired 802.1x Authentication
    Port Mirroring
    Local DNS Server
    Conditional DNS Forwarding
    Hotspot Web Portal
    Hotspot Authentication Click-Through, Social Login, SMS PIN
    Networking
    Routing IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2
    Policy-based Routing Protocol, IP Address, Port, Domain
    IGMP IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave
    DNS Security (DNSSEC)
    Local RADIUS server
    SMB File Sharing (Requires external storage)
    VPN
    LAN-to-LAN
    Teleworker-to-LAN
    Protocols PPTP, L2TP, IPsec, L2TP over IPsec, IKEv2, IPsec XAuth, IKEv2 EAP, GRE, SSL, OpenVPN(Host to LAN)
    User Authentication Local, RADIUS, LDAP, TACACS+, mOTP
    IKE Authentication Pre-Shared Key, X.509
    IPsec Authentication SHA1, SHA256, MD5
    Encryption MPPE, DES, 3DES, AES128, AES192, AES256
    VPN Trunk (Redundancy) Load Balancing, Failover
    NAT-Traversal (NAT-T)
    Firewall & Content Filtering
    NAT Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP
    ALG (Application Layer Gateway) SIP, RTSP, FTP, H.323
    VPN Pass-Through PPTP, L2TP, IPsec
    IP-based Firewall Policy
    Content Filtering Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required)
    DoS Attack Defense
    Bandwidth Management
    IP-based Bandwidth Limit
    IP-based Session Limit
    QoS (Quality of Service) TOS, DSCP, 802.1p, IP Address, Port, Application
    VoIP Prioritization
    Wireless LAN (wireless model)
    Number of SSID 4
    Security Mode WEP, WPA, WPA2, Mixed(WPA+WPA2)
    Authentication Pre-Shared Key, 802.1X
    WPS PIN, PBC
    WDS Bridge, Repeater
    Access Control Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling
    AirTime Fairness
    WMM
    Management
    Local Service HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069
    Config File Export & Import
    Config File Compatibility Vigor2830, Vigor2830v2, Vigor2820
    Firmware Upgrade TFTP, HTTP, TR-069
    Access Control Access List
    2-Level Administration Privilege
    Syslog
    Notification Alert SMS, E-mail
    SNMP v2, v2c, v3
    Managed by VigorACS
    Physical
    Power Supply DC 12V @ 1.5-2A
    Max. Power Consumption 18 watts
    Dimension 241mm x 166mm x 46mm
    Weight 0.53kg (n model)
    Operating Temperature 0 to 45°C
    Storage Temperature -25 to 70°C
    Operating Humidity (non-condensing) 10 to 90%
    Certificate CE FCC

    All specifications are subject to change without notice.

    In-the-Box

    Vigor2832

    Antenna x 2
    (ac model)

    RJ-11 to RJ-11 Cable
    (Annex A)

    RJ-45 Cable
    (Ethernet)

    Power Adapter

    Quick Start Guide
