- Fixed WAN Port
1 x RJ-11, VDSL2 35b/ADSL2+ - Fixed LAN Port
5 x GbE, RJ-45 - Switchable WAN/LAN Port
1 x GbE, RJ-45 - USB Port
2 x USB 2.0
Vigor2865 Series is a VDSL2/ADSL2+ Security Firewall router integrating a DSL modem which is compatible with variants of ADSL and VDSL, including VDSL Super Vectoring. There is also a Gigabit Ethernet WAN port for broadband connections to share the traffic load or being used as a failover connection. 3G/4G/LTE USB modem can also be attached to the USB ports of the router, and offer wireless Internet connectivity in case the fixed lines are not available.
Vigor2865Lac has a built-in 3G/4G/LTE modem, cellular connectivity can be added by simply inserting a SIM card. Vigor2865 Series can also be a central management portal for Vigor APs and Vigor Switches, providing Network Administrator a simpler way to maintain all the network devices.
VDSL2 35b
Download speed
up to 300 Mbps
Up to 4 WAN
Load balancing, NAT throughput up to
800 Mbps
32 VPN
IPsec VPN throughput
up to 300 Mbps
60k Sessions
Recommended for
30 clients
Key Features
Load Balancing
Maximize throughput and reliability by using multiple Internet connections.
QoS for VoIP
Give first priority to VoIP traffic to improve your call quality, and monitor VoIP statistics from the router.
35b Supervectoring Modem
Integrated VDSL modem with 35b Supervectoring compatibility and VDSL2/ADSL2+ fallback.
Bandwidth Management
Prevent one device using all the bandwidth by bandwidth limit policy, session limit policy, and QoS settings.
VPN (Virtual Private Network)
Build a secure and private tunnel from the LAN of Vigor3910 to the remote offices and teleworkers over the Internet.
Central AP Management
Use the Vigor2865 router as a wireless controller to maintain and monitor the VigorAPs.
SSL VPN
The VPN works through firewalls providing secure remote access to any network environment.
Central Switch Management
Set up VLAN easily from the router and get a centralized hierarchy view of the switches.
Wireless WAN (Wireless model only)
Get Internet access wirelessly from a Wi-Fi network, a mobile hotspot, or a personal hotspot set up on smartphones.
Firewall & Content Filter
Filter web pages by URL keyword or web category to block access to insecure or inappropriate contents.
DrayDDNS
The free DDNS service for you to access the router by a fixed hostname of your choice.
Hotspot Web Portal
Market your business and communicate with the guests while offering hospitality Wi-Fi.
Interface | |
---|---|
Fixed WAN Port | 1x RJ-11 for VDSL2 or ADSL2/2+ |
LAN/WAN Switchable Port | 1x 10/100/1000Base-TX RJ-45 |
Fixed LAN Port | 5x 10/100/1000Base-TX RJ-45 |
USB Port | 2x USB 2.0 |
2.4G WLAN | 802.11n 2×2 MIMO 400Mbps (ac model) |
5G WLAN | 802.11ac 2×2 MIMO 867Mbps (ac model) |
Performance | |
NAT Throughput | 800 Mbps |
IPsec VPN Performance | 300 Mbps (AES 256 bits) |
SSL VPN Performance | 120 Mbps |
Max. Number of NAT Sessions | 60,000 |
Max. Concurrent VPN Tunnels | 32 |
Max. Concurrent OpenVPN + SSL VPN | 16 |
VDSL/ADSL | |
VDSL Standards | G.993.2 (VDSL2), G.993.5 (vectoring) |
VDSL2 Profile | 8a, 8b, 8c, 8d, 12a, 12b, 17a, 35b |
ADSL Standards | ANSI T1.413, ITU-T G.992.1(G.dmt) |
ADSL2 Standards | ITU-T G.992.3 Annex A/L/M |
ADSL2+ Standards | ITU-T G.992.5 Annex A/M |
Internet Connection | |
IPv4 | PPPoE, DHCP, Static IP, PPTP/L2TP |
IPv6 | PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
802.1p/q Multi-VLAN Tagging | |
Multi-VLAN/PVC | |
3G/4G/LTE WAN with USB modem | |
Load Balancing | IP-based, Session-based |
WAN Active on Demand | Link Failure, Traffic Threshold |
Connection Detection | ARP, Ping |
WAN Data Budget | |
Dynamic DNS | |
DrayDDNS | |
LAN Management | |
VLAN | 802.1q Tag-based, Port-based |
Max. Number of VLAN | 16 |
DHCP Server | Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
LAN IP Alias | |
Wired 802.1x Authentication | |
Port Mirroring | |
Local DNS Server | |
Conditional DNS Forwarding | |
Hotspot Web Portal | |
Hotspot Authentication | Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server |
Networking | |
Routing | IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP, BGP |
Policy-based Routing | Protocol, IP Address, Port, Domain, Country |
High Availability | |
DNS Security (DNSSEC) | |
Multicast | IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour |
Local RADIUS server | |
SMB File Sharing | (Requires external storage) |
VPN | |
LAN-to-LAN | |
Teleworker-to-LAN | |
Protocols | PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN |
User Authentication | Local, RADIUS, LDAP, TACACS+, mOTP |
IKE Authentication | Pre-Shared Key, X.509 |
IPsec Authentication | SHA-1, SHA-256 |
Encryption | MPPE, DES, 3DES, AES |
VPN Trunk (Redundancy) | Load Balancing, Failover |
Single-Armed VPN | |
NAT-Traversal (NAT-T) | |
Firewall & Content Filtering | |
NAT | Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
ALG (Application Layer Gateway) | SIP, RTSP, FTP, H.323 |
VPN Pass-Through | PPTP, L2TP, IPsec |
IP-based Firewall Policy | |
Content Filtering | Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
DoS Attack Defense | |
Spoofing Defense | |
Bandwidth Management | |
IP-based Bandwidth Limit | |
IP-based Session Limit | |
QoS (Quality of Service) | TOS, DSCP, 802.1p, IP Address, Port, Application |
VoIP Prioritization | |
Wireless LAN (ac model) | |
Number of SSID | 4 per radio band |
Security | WEP, WPA, WPA2, WPS |
Authentication | Pre-Shared Key, 802.1X |
WDS | Bridge, Repeater (5G Only) |
Access Control | Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling |
AirTime Fairness | |
Band Steering | |
WMM | |
Management | |
Local Service | HTTP, HTTPS, Telnet, SSH, FTP, TR-069 |
Config File Export & Import | |
Firmware Upgrade | TFTP, HTTP, TR-069 |
2-Level Administration Privilege | |
Access Control | Access List, Brute Force Protection |
Notification Alert | SMS, E-mail |
SNMP | v1, v2c, v3 |
Syslog | |
Managed by VigorACS | |
Central VPN Management | 8 VPN |
Central AP Management | 20 VigorAP |
Central Switch Management | 10 VigorSwitch |
Physical | |
Power Supply | DC 12V @ 4A-4.5A |
Max. Power Consumption | 24 watts (ac model) |
Dimension | 241mm x 166mm x 46mm |
Weight | 620g (ac model) |
Operating Temperature | 0 to 45°C |
Storage Temperature | -25 to 70°C |
Operating Humidity (non-condensing) | 10 to 90% |
All specifications are subject to change without notice.
2.4 GHz | 5 GHz | |
---|---|---|
Vigor2865ac | ||
Vigor2865 | – | – |
